What this integration is

This integration ingests CrowdStrike Falcon events into your SOCFortress SIEM stack using the Falcon SIEM Connector (FalconHose). CrowdStrike events are forwarded to your SIEM (typically Graylog) over syslog, where they can be searched, routed, and used for alerting and investigations. Vendor references:

​
Prerequisites

  • CrowdStrike Falcon console access
  • An API client created with scope that includes read access for Event streams
Important:
  • If you are in CrowdStrike Government cloud, you must open a support ticket with CrowdStrike to enable the Falcon SIEM Connector.
CrowdStrike API Settings

​
Configuration (Falcon SIEM Connector)

Connector configuration is stored at:
  • /opt/crowdstrike/etc/cs.falconhoseclient.cfg
CoPilot provisioning typically generates this for you, but for reference the key values that must be set include:
  • api_url
  • client_id
  • client_secret
  • syslog_host / syslog_port
Example configuration:
[Settings]
version = 3
api_url = REPLACE_BASE_URL/sensors/entities/datafeed/v2
request_token_url = REPLACE_BASE_URL/oauth2/token
app_id = SIEM-Connector-v2.0.0

enable_correlation_id = false
format_floats_as_scientific = true

# API Client ID
client_id = REPLACE_CLIENT_ID
# API Client Secret
client_secret = REPLACE_CLIENT_SECRET

# Amount of time (in seconds) we will wait for a connect to complete.
connection_timeout = 10
# Amount of time to wait (in seconds) for a server's response headers after fully writing the request.
read_timeout = 30

# Specify partition number 0 to n or 'all' (without quote) for all partitions
partition = all

http_proxy =

# Output formats
# Supported formats are
#   1.syslog: will output syslog format with flat key=value pairs uses the mapping configuration below.
;             Use syslog format if CEF/LEEF output is required.
#   2.json: will output raw json format received from FalconHose API (default)
output_format = syslog

# Will be true regardless if Syslog is not enabled
# If path does not exist or user has no permission, log file will be used
output_to_file = false
output_path = /var/log/crowdstrike/falconhoseclient/output

# Offset file full filepath and filename
offset_path = /var/log/crowdstrike/falconhoseclient/stream_offsets

[Output_File_Rotation]
# If the output is writing to a file, then the settings below will govern output file rotation
#
# If true, then the rotation rules will apply. If not, the client will continue to write to the same file.
rotate_file = true
# Maximum individual output file size in MB
max_size = 500
# Number of backups of the output file to be stored
max_backups = 10
# Maximum age of backup output files before it is deleted in DAYS
max_age = 30

[Logging]
verbose_log = true
# Maximum individual log file size in MB
max_size = 500
# Number of backups to be stored
max_backups = 10
# Maximum age of backup files before it is deleted in DAYS
max_age = 30

[Syslog]
send_to_syslog_server = true
host = REPLACE_SYSLOG_HOST
port = REPLACE_SYSLOG_PORT
protocol = tcp

​
CoPilot provisioning

Once you have saved the CrowdStrike configuration for the customer, you are ready to deploy the integration. In CoPilot, navigate to the Customers section and select the appropriate customer. Provisioning typically creates:
  • Graylog CEF input
  • Graylog stream
  • Graylog index
  • Grafana datasource
  • Grafana dashboards
  • CrowdStrike docker compose file

​
Deployment (connector container)

The CrowdStrike integration runs via a docker container. During provisioning, a customer directory is created:
  • /opt/CoPilot/data/data/<CUSTOMER_NAME>
Inside you’ll typically find:
  • <CUSTOMER_NAME>_docker-compose.yml
  • cs.falconhoseclient.cfg
Start the container:
docker compose -f /opt/CoPilot/data/data/<CUSTOMER_NAME>/<CUSTOMER_NAME>_docker-compose.yml up -d
You should now see the container running: CrowdStrike Running Container

​
Success criteria

  • CrowdStrike events are arriving in Graylog
  • Events are routed to the correct customer stream/index
  • Dashboards populate (after a short delay)

​
Troubleshooting

  • No events:
    • verify Falcon SIEM Connector is enabled for your tenant (GovCloud note above)
    • confirm API client has event stream read scope
    • check connector container logs
  • Events arriving but not routed:
    • confirm Graylog input/stream/index created during provisioning
    • confirm syslog host/port match your Graylog input
